Flow Switch Type 16-01

products

Flow Switch Type 16-01  Flow Switch Type 16-01 Flow Switch Type 16-01

Product information

  • Product Title : Flow Switch Type 16-01
  • Production code : FS Type 16-01
  • Professional Name : Flow Switch Type 16-01

General information Flow Switch Type 16-01 Flow Switch Type 16-01

This device has a micro switch which stimulates it's own particular blade. With this capability is able to control fluid flow inside the pipe by sending command to different electrical devices, such as pumps or electro motors or etc. This type of flow switch is S.P.D.T and is used in the non-flammable liquid line.



Function Flow Switch Type 16-01 Flow Switch Type 16-01

This type of flow switch can not be used in liquid pipe lines which have lower temperature than the freezing point.

To function properly, the bland must not grip to the bottom of pipe. So , choose suitable  blades according to pipe size. Appropriate bland height for each pipe size  can  be observed in following diagram.

Installation Flow Switch Type 16-01 Flow Switch Type 16-01

Flow switches type FS 16-01 have to be installed through 1" socket (rather vertically) at top side of the pipe line. If device is installed horizontally, the fluid flow should be upward. Because of gravity, device make an error in contrariwise installation.

Attention: Please, note to arrow on body for correct installation

Factory adjustment is set on minimum flow rang. Please, do not decrease  the flow less than factory adjustment .otherwise , the flow switch  dose not command to flow interruption.



Download product Catalogue and installation tutorial Flow Switch Type 16-01 Flow Switch Type 16-01

Product Catalogue Flow Switch Type 16-01 Flow Switch Type 16-01 Manual installation - PDF Flow Switch Type 16-01 Flow Switch Type 16-01

:
